Tempo Communications 177-G Precision Tone Generator
Tempo 177-G precision tone generator producing a crystal-controlled 577.5 Hz pulsed tone, supplied with three piercing test leads, 6 V lantern battery and carrying case.
Damaged or lost in transit? Let us know within 7 days.
Product details
The Tempo Communications 177-G Precision Tone Generator is a portable, battery-operated tone generator for cable identification, fault location, and pair identification. It transmits a crystal-controlled 577.5 Hz tone pulsed at 1 Hz that can be reliably detected even in high-noise or power-influenced environments where other tones fail. A -27 to +27 dBm adjustable output lets technicians set the signal level for each job, and three insulation-piercing test leads plus a woven polyester carrying case make it field-ready.
- Brand
- Tempo Communications
- SKU / MPN
- TEMP177-G
Product Specifications
- Transmitter frequency: 577.5 Hz, pulsed at 1 Hz, crystal controlled
- Adjustable output level: -27 to +27 dBm (output signal level 0 to +30 dBm)
- Output voltage: 0.1 to 80 Vp-p
- Effective for toning in high circuit noise or power-influenced areas
- Three test leads with bent-nose piercing clips and bed-of-nails insulation-piercing pins
- Red LED battery condition indicator
- Power: one 6V lantern battery; battery life approx. 40 hours nominal
- Dimensions: 7.25 IN x 5.5 IN x 4.5 IN in case
- Weight: 3 lbs with battery
- High-impact ABS plastic housing in durable woven polyester case with shoulder strap
